SPEED • FLEXIBILITY • ACCURACY

Standard equipment

• 2D graphic controller, 8” color Touch-Screen, CybTouch8
• Y1, Y2 independent hydraulic cylinders, proportional valve technology
• Single-axis back gauge system X
• Mechanical upper tool clamping
• Mechanical lower tool clamping
• Efficient, low-noise and accurate hydraulic system
• Beam movement on two double roller bearings on each side
• Strong and stable construction
• Bending Force: 40tons
• Working Length: 1550mm
• Distance between uprights: 1550mm
• Daylight: 400mm
• Punch Stroke: 200mm
• Fast Speed: 260mm/sec
• Working Speed: 20mm/sec*
• Upstroke Speed: 200mm/sec
• Back gauge speed: 800mm/sec
• Main Electric Motor: 7.5kW
• Weight: 4.500kg
• Dimensions: 2300 x 1550 x 2500mm

* Working speed is limited according to safety regulations for CE countries.
